| Model | HFPA0360 |
|---|---|
| Frequency [MHz] min | 250 |
| Frequency [MHz] max | 6000 |
| Gain [dB] | 38 |
| Output level [dBm] | 28 |
| Noise figure [dB] | 2.2 |
| IP3 [dBm] | 40 |
| Power [V] | 14.5-16 |
| Connector | SMA |
Additional information
HFPA0360
HFPA0360 is wideband high power amplifier. Amplifier provides for high gain and high output power in very wide frequency range 250MHz up to 6000MHz. Solid enclosure and modern components ensure reliable work within entire frequency range.
KEY FEATURES:
-
Wideband 250-6000MHz
-
High gain 38dB
-
High output power +30dBm
-
Excellent flatness ±1dB
-
High OIP3
-
Compact and reliable
APPLICATIONS:
-
Measuring
-
Communication
-
Laboratory
-
Antenna systems
-
Military applications
-
LTE/UMTS/GSM/DCS
-
Wi-Fi/WiMax
-
TETRA
